LCD

5" Colorful touch screen

7" Colorful Touch Screen

keyboard

Reading Cuvette

Both flow through cell and direct reading cuvette

Aspiration Volume

450 ul – 500 ul

Incubator

20 incubating positions

Photometric System

Light Source:6V/10W halogen lamp

Wavelength:340/405/492/510/546/578/620nm,2 more filters on request

Wavelength Accuracy:±2nm

Thermostatic Control

Temperature:25℃,30℃,37℃

Precision:±0.1℃

Measuring System

Method: End point, Fixed time, Multistandard,Differential, Bichromatic and Immunoturbidimetric, etc.

Mearsuring Range:0~3.000 O.D

Photometric Linearity:±2%(0~3.000 O.D)

Photometric Accuracy:±1%(0~3.000 O.D)

Carry-over:≤1%

Drift

<0.005 O.D/hr

Test Menu

 T.BILI      r-GT/GGT   CHO   Ca   APOB-1/B   CHE

 D.BILI     ALP/AKP   TG     CL   APOB       CREA

 TP         UREA      CK     P    CK-MB      Mg

 ALB        CREA      LDH    C    ASO        AFU

 Lactic Acid   ALT/GPT   UA   α-HBDH  CO2     FMN

 LP(a)       AST/GOT    GLU   AMY   LDL-C   HDL-C

 CHE         LA        TBA    ADA    HS-CRP   PA

 Fe           Cu        Zn      C3     C4      lgG

 lgM          lgA        and drug,toxicity,etc

Quality Control

Excellent Q.C.function,Q.C.chart may be displayed and printed
