Advantage

1, fast

• Can quickly detect defects in metal, plastic and composite welded joints and provide detailed results.

• Can visualize the internal structure of the detected object, real-time imaging part, 25 frames/SEC picture update rate.

• Enables ultrasonic inspection along the weld without cross-scanning (due to the large aperture of the digital focus array and the long-distance scanning of the virtual focus), greatly reducing the preparation time of the weld surface and improving detection efficiency.

• Provides a high picture refresh rate, enabling a scan speed of up to 50mm/s at welded joints.

2. The data is easy to interpret

• Visualization of the internal structure of objects, with cross sections (B-Scan) presented in graphical and real-time imaging form, and easy-to-use length and depth rulers that make the results easier to analyze.

• Automatically or manually measure the signal level, location and dimensions of defects.

• Distance measurement between defect images on the screen.

Operating characteristics

• A-Scan capability in tomography mode, allowing visualization of A-scan pulses and drawing cross sections of control curves. It also evaluates FLAW depth and probe incidence Angle, enabling quick and correct selection of a single probe when switching to FLAW DETECTOR mode

• Measure reflector position and signal across the fault scan surface

• Set the position of the ruler and visual area associated with the DFA

•2 adjustable gates for automatic measurement of defect location

• Adjust the contrast of the tomography directly

• Create, save and select specific objects

• Save and view tomography images and echo signals from a memory card

• Through the calibration test block, semi-automatic calibration
