| Technology Parameter | ||
| Generator | power | Voltage:3 Phase,220V;Frequency: 50Hz±1Hz |
| instant Maximum Power: 3.5kW 100kV, | ||
| 35mA | ||
| Fluoroscopy | Pulse Fluoroscopy: 0.1mA- | |
| 25mA,40kV-110kV | ||
| Continuous Fluoroscopy: 0.1mA-5mA, 40kV-110kV | ||
| Radiography | 40kV-110kV, step adjustment | |
| 23mA-80mA | ||
| X-ray tube | Voltage | 110KV |
| Focus | 0.6/1.5mm | |
| Heat capacity | 500KJ | |
| C-arm | right :±12.5°, error ±2° | |
| C-arm rotating around horizontal | ||
| support: ±180°, error ±2° | ||
| Image | CCD camera | 1000, 000 pixel |
| system | intensifier | 14'' monitor |
