| Generaor | Collimator | ||
| Frequency | 200KHz+ | Type | Manual ( with location light ) |
| kV Range | 40-150kV | Motorized Adjustment Radiographic Table | |
| mA Range | 10-630mA | SID | ≤115cm |
| mAs Range | 0.1-630mAs | Tabletop | 200(L)×74(W)×66(H)cm |
| Power | 50kW | Transverse Travel | ±10cm |
| X-ray Tube | Longitudinal Travel | ±60cm | |
| Focal Spot | 0.6/1.2mm | Grid | |
| Heat Capacity | 150KHU | r | 10:1 |
| Max. kV | 150Kv | f | 100cm |
| Max. mAs | 370/760mA | N | 40 Line/cm |
| Tube Rotation | ±180° | Wall Stand | Optional |
| Travel Range | 120cm | Ion Chamber | Optional |
