Reading cuvette | Quartz flow through cell |
Measuring volume | 450ul - 800ul |
Incubator | None |
Photometric system | Light source: 6V/10W halogen lamp; standby function |
Wavelength:340/405/492/510/546/578/620nm, 2 more filters available on request |
Wavelength Accuracy:±2nm |
Thermostatic control | Temperature: 25℃, 30℃,37℃ |
Precision:±0.1℃ |
Measuring system | Method: End point, Fixed time, Multistandard, Differential, Bi-chromatic, etc. |
Method range: 0-3.000 O.D |
Photometric Linearity: ±2%(0-3.000 O.D) |
Photometric Accuracy: ±1%(0-3.000 O.D) |
Carry-over: ≤1% |
Drift | <0.005O.D/hr |
Test Menu | T.BILI r-GT/GGT CHO Ca APOB-1/B CHE TP CK D.BILI ALP/AKP TG CL APOB CREA UREA P CK-MB Mg ALB CREA LDH C ASO AFU HS-CRP Lactic Acid UA a-HBDH CO2 FMN LP(a) AST/GOT PA ALT/GPT GLU AMY LDL-C HDL-C LA TBA ADA Fe Cu Zn C3 C4 lgG lgM lgA and drug,toxicity,etc |
Quality control | Excellent Q.C. function, Q.C.chart can be displayed and printed |
Display | Back-illuminated LCD; Color Touch Screen |
Storage | Over 180 programs,3000 test results |
Printer | Built-in thermal printer |
Software | For computer communication on request |
Interface | RS232 serial port, USB port on request |
Power supply | AC110V/60HZ or 220V/50HZ |
Dimensions | 34cm×38cm×18cm |
Weight | 7.0kg |
