| Specification | |
| Monitor Size | High resolution 15" LED display |
| Imaging Modes | B, B|B, 4B, B|M, M |
| Color Doppler (CF), Power Doppler (PDI), Directional Power Doppler (DPDI) | |
| Pulsed Wave Doppler (PW) | |
| Continuous Wave Doppler (Optional) | |
| B+CF (Dual Images) | |
| M+CF | |
| B+PW (Duplex), B+CFM/PDI/DPDI+PW (Triplex) | |
| High Pulse Repetition Frequency (HPRF) | |
| Tissue Harmonic Imaging (THI), Pulse Inversion Tissue Harmonic Imaging (iTHI) | |
| Tissue Specific Imaging | |
| Convex Extended Imaging | |
| Linear Trapezoid Imaging | |
| Spatial Compound Imaging | |
| Wide Range Imaging (Optional) | |
| 3D/4D Imaging (Optional) | |
| Scanning Method | electronic linear, electronic convex, electronic micro-convex, electronic phased array, 4D probe, scanning depth: 2-30cm |
| Color Doppler | PRF variable: 0.6-20kHz |
| Wall filter settings: ≥ 5 steps | |
| Angle steering for linear transducers: ±5°, ±10°, ±15° | |
| Real-time spatial filter: ≥ 4 values | |
| CFM palette: ≥10 maps | |
| PDI palette: ≥10 maps | |
| B/Color priority control | |
| Color threshold control | |
| CFM baseline control | |
| Doppler frequency selection: ≥ 4 values | |
| Color frame averaging | |
| Transparent Color Mapping (TCM) | |
| Pulsed Wave Doppler | PRF variable: 0.6-20 kHz |
| Wall filter settings: ≥ 10 steps | |
| Angle steering for linear transducers: ±5°, ±10°, ±15° | |
| Real-time trace line with automatic calculation of spectrum parameters | |
| Stereo sound: volume control | |
| PWD palette: ≥10 maps | |
| Doppler frequency selection: ≥ 4 values | |
| Processing | Multi-beamform Imaging |
| High Line Density scan mode for better resolution | |
| 8 sliders TGC Control | |
| Dynamic Range: ≥120 dB | |
| Overall gain control | |
| M mode sweep speed control | |
| Acoustic power control | |
| Variable frame averaging | |
| Advanced gamma control | |
| Scan direction, rotation, up-down controls | |
| Negative / positive control | |
| Echo enhancement control | |
| Noise rejection function | |
| Speckle reduction | |
| Image and video | AVI, JPG, BMP, PNG, TIF, DCM (DICOM) etc |
| General Measurements and Calculations | Distance, Length, Area, Circumference, Volume, Angle, Stenosis %, A/B Ratio, Velocity, Pressure Gradient (PG), Acceleration, |
| Resistivity Index (RI), Heart Rate, Velocity Time Integral (VTI), etc. | |
| Measurements and Calculations Software Packages | Obstetrics, Gynecology, Abdominal, Urology, Endocrinology, Vascular, Cardiology, etc. |
| Expansion interfaces | VGA, TV Interface |
| USB Interface | |
| RJ-45 Network interface | |
| Support DeskJet printer, LaserJet printer, video printer | |
| Configuration | |
| Standard Configuration | Optional Configuration |
| Main unit: 1 pc | Phased array probe(Incl. CW software) |
| Two probe sockets, automatically identify probe | 6.5MHz TV probe |
| 3.5MHzmulti-frequency abdomen convex probe:1pc | 4D volume probe(Incl. 4D software) |
| 7.5MHz linear probe: 1 pc | 3D software |
| Internal Li-battery: 1 pc |
