| Input power | Voltage: AC220V±22v , frequency: 50/60Hz±1Hz; Power capacity: ≥5kVA; lnner resistance≤0.5Ω |
| Maximum output power | P=11OkV×36mA=4kW |
| Nominal power | 100kV，40mA，0.1s，4kW |
| Frequency | ≥40kHz |
| KV adjusting range | 40kV～110kV, step adjustment is 1 kV |
| mA adjusting range | 36mA～70mA |
| mAs adjusting range | 1mAs-200mAs,shifted adjustment |
| s adjusting range | 0.04s~3.2s |
| x ray tube | Focus:0.6/1.5mm; Anode heating capacity:76kHU |
| Size | 290×260×230mm |
| Weight | 18.8kg |
| Accessories | 1.Remote control 2.Aluminum box 3.Machine frame |
