Tech Parameters：
l 10.4’ high resolution color LED backlight display, with high contrast and wide viewing angle；
l Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable.
l Menu operation system, with different languages according to requirement including Spanish, English, French, Russian and Portuguese；
l Two probe sockets, auto-identify different optional probe；
l Body marks：total 64 kinds body marks indicating probe position；
l Display mode：B、2B、4B 、B/M、M ；
l Adjustable depth: 10 grades, max depth to 236mm；
l Gain：0～127dB；
l Contrast：27～90dB；
l Gray scale：256；
l 8 steps intelligent TGC；
l Frame frequency: 30 frames /second
l 8 kinds pseudo colors；
l Image storage: 4G hard disk to permanently store about 5000 frames images；without loss when power off.
l Cine loop：256 frames；
l Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position)；
